Kingtech 3.5" inch 640*480 TFT module display supply very stable. This 3.5" inch supports MIPIinterface. In addition, the 3.5" inch TFT display module brightness is 500nits for sunlight readable, and this 3.5inch screen is All viewing type. For the touch part, we can also customize capacitive and resistive touch according to the customer requirements.
Stable supply
500nits brightness/Sunlight readable/High brightness/Outdoor
-20~70/Wide working temperature
Can custom resistive touch and capacitive touch
Get a Quote
Documentation
| Item | 3.5" IPS 640*480TFT display |
| Model No. | PV03526D0130Z |
| Resolution | 640*480 |
| Outline Dimension (mm) | 76.74*63.74*3.20 |
| Active Area (mm) | 70.08*52.56 |
| Viewing Angle | All |
| Brightness | 500nits |
| Interface | MIPI |
| Backlight | 6*1LEDs |
| Driving IC | NV3051 |
| PIN No. | 30 |
| Operating Temperature | -20~70C |
| Storage Temperature | -30~80C |
| Touch screen | Can custom resistive and capacitive touch screen |
| Application | E-Bike, Medical, Hand-held device, Industrial |
The 3.5" inch 640*480 TFT display module can be used for Medical, hand-held device, industrial, outdoor, Elevator, Access Control device, E-bike, EV-chargers.
