Kingtech 3.4 inch 480*480 TFT display supply very stable. This 3.4 inch supports MIPI interface. In addition, the 3.4 inch 480*480 TFT display module brightness is 300 nits, and this 3.4 inch display is All viewing type. For the touch part, we can also customize capacitive and resistive touch according to the customer requirements.
3.4 inchTFT display
480*480
Stable supply
All/Full/Wide/IPS viewing angle
MIPI interface
300nits brightness/Sunlight readable/High brightness
Can custom resistive touch and capacitive touch
Medical, hand-held device, industrial, smart-home
Get a Quote
Documentation
| Item | 3.4 inch IPS 480*480 square TFT LCD display |
| Model No. | PV03404G0130E |
| Resolution | 480*480 |
| Outline Dimension (mm) | 70.45*70.32*1.89 |
| Active Area (mm) | 60.48*60.48 |
| Viewing Angle | All |
| Brightness | 300nits |
| Interface | MIPI |
| Backlight | 4*2LED |
| Driving IC | ST7701S |
| PIN No. | 30 |
| Operating Temperature | -20~70 |
| Storage Temperature | -30~80 |
| Touch screen | Can custom resistive and capacitive touch screen |
| Application | Medical, hand-held device, industrial, smart home |
The 3.4 inch 480*480 TFT display module can be used for E-Bike, Medical, hand-held device, industrial, smart-home or others.
