Kingtech 21.5 inch 1920x1080 IPS LCD display supply is very stable. This 21.5 inch supports LVDS, MIPI, and eDP interfaces. In addition, the 21.5 inch TFT module lifetime is 30000h, the brightness is 1000nits sunlight-readable, and this 21.5-inch screen is All/Free/Full/Wide viewing angle/IPS type. For the touch part, Kingtech can custom the touch according to the customer's requirements.
All/Free/Wide viewing angle/IPS
1920x1080
Color Gamut 72%NTSC
Stable supply
HDMI board/Convert board
Wide temperature/-5℃~+60℃
High brightness/Sunlight readable/outdoor/1000nits
Can custom capacitive touch screen
Get a Quote
Documentation
| Item | 21.5inch 1080x1920 LCD display |
| Model No | PV215001HS30B |
| Resolution | 1080x1920 |
| Outline Dimension | 267.28(W)×489.956(H)× 10.67(T) |
| Active Area(mm) | 260.28(H)*478.656(V) |
| Interface | LVDS / MIPI / eDP interfaces |
| Brightness | 1000nits |
| Viewing Angle | All |
| LED life | 30000h |
| Display Mode | TN / Transmissive / Normally Black |
| Color Gamut | 72%NTSC |
| PIN | 30 |
| Operating Temperature | -5℃~60℃ |
| Storage Temperature | -20℃~60℃ |
| Touchscreen | Can custom capacitive touchscreen |
The 21.5inch 1920x1080 IPS TFT LCD display can be used for industrial control, agricultural equipment, medical device, game console, outdoor and smart homes, etc.
