Kingtech 4.3 inch 480*272 TFT display supply very stable. This 4.3 inch supports 24-BIT RGB interface. In addition, the 4.3 inch 480*272 TFT display module brightness is 480 nits, and this 4.3 inch WQVGA display is 12 O'clock viewing type. For the touch part, we can also customize capacitive and resistive touch according to the customer requirements.
4.3 inchTFT display
480*272/WQVGA
Stable supply
12 O'clock
24-BIT RGB interface
480nits brightness/Sunlight readable/High brightness
Can custom resistive touch and capacitive touch
Medical, hand-held device, industrial
Get a Quote
Documentation
| PV043027D0140X | 4.3 inch TN 480*272 TFT display |
| Model No. | PV043027D0140X |
| Resolution | 480*272 |
| Outline Dimension (mm) | 105.5*67.2*2.95 |
| Active Area (mm) | 95.04*53.86 |
| Viewing Angle | 12 O'clock |
| Brightness | 480nits |
| Interface | 24-BIT RGB |
| Backlight | 5*2 LED |
| Driving IC | HX8257A |
| PIN No. | 40 |
| Operating Temperature | -20~70C |
| Storage Temperature | -30~80C |
| Touch screen | Can custom resistive and capacitive touch screen |
| Application | E-Bike, Medical, Hand-held device, Industrial |
The 4.3 inch 480*272 TFT display module can be used for E-Bike, Medical, hand-held device, industrial or others.
