Kingtech 12.1 inch 1280*800 TFT display supply very stable. This 12.1 inch supports LVDS interface. In addition, the 12.1 inch 1280*800 TFT display module brightness is 1000 nits, and this 12.1 inch WXGA display is All viewing type. For the touch part, we can also customize capacitive and resistive touch according to the customer requirements.
12.1 inchTFT display
1280*800/WXGA
Stable supply
IPS/Full/Wide/All viewing angle
LVDS interface
1000nits brightness/Sunlight readable/High brightness/Outdoor
Can custom resistive touch and capacitive touch
Medical, hand-held device, industrial
Get a Quote
Documentation
| Item | 12.1inch IPS 1280*800 TFT display |
| Model No. | PV012106S0130G |
| Resolution | 1280*800/WXGA |
| Outline Dimension (mm) | 278*184*10 |
| Active Area (mm) | 261.12*163.2 |
| Viewing Angle | All |
| Brightness | 1000nits |
| Interface | LVDS |
| Backlight | / |
| Driving IC | / |
| PIN No. | 30 |
| Operating Temperature | -30~80C |
| Storage Temperature | -30~85C |
| Touch screen | Can custom resistive and capacitive touch screen |
| Application | Medical, hand-held device, industrial, |
The 12.1 inch 1280*800/WXGA TFT display module can be used for E-Bike, Medical, hand-held device, industrial or others.
