Kingtech 0.96 inches 80*160 TFT module display supply is very stable. This 0.96 inch supports 4 Line SPI Interface. In addition, the 0.96 inch TFT display module brightness is 300 nits, and this 0.96-inch screen is All/Free/Wide viewing angle/IPS type. For the touch part, we can also customize capacitive touch according to the customer's requirements.
TFT display
80x160
Stable supply
All/Free/Wide viewing angle/IPS
Small/tiny display
4 Line SPI interface
Smartwatch/wearable
Can custom capacitive touch
Get a Quote
Documentation
| Item | 0.96inch TFT module display |
| Model No | PV096000AR13A |
| Resolution | 80x160 |
| Outline Dimension | 13.5(H)x27.95(V)x1.5(D) |
| Active Area(mm) | 10.8(H)x21.7(V) |
| Brightness | 300nits |
| Viewing Angle | All |
| Interface | 4 Line SPI |
| Driving IC | ST7735S |
| Display Mode | Transmission / Normally Black |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
| Touch screen | Can custom capacitive touch screen |
The 0.96 inch 80x160 TFT display module can be used for Smartwatch and wearables.
