Kingtech PV07056Y0130H is a 7.0” color TFT liquid crystal display (LCD) with a module size of 164.8*100*2.8mm and active area of 154.21*85.92mm. This product is a-Si TFT, Negative, Transmissive glass with 1024x600 resolution. Its brightness is 400 nits with a contrast ratio of 1000. It is with MIPI interface. This product offers improved contrast, color saturation and response time.
7.0 inch TFT LCD display
1024x600
Stable supply
Full/All/IPS/Wide Viewing angle
MIPI Interface
400nits brightness
Without/with touch
Advertising display, medical, automotive, IoT, home application, Gas equipment, Medical, Industrial control, Elevator, Car automation, Surveillance video
Get a Quote
Documentation
| Item | 7.0 inch TFT 1024x600 module display |
| Model No. | PV07056Y0130H |
| Resolution | 1024*600 |
| Outline Dimension (mm) | 164.8*100*2.8 |
| Active Area (mm) | 154.21*85.92 |
| Viewing Angle | All |
| Brightness | 400nits |
| Interface | MIPI Interface |
| Backlight | 3*8LED |
| Pin nums | 30 |
| Driving IC | / |
| PIN No. | 30 |
| Operating Temperature | -20~70 |
| Storage Temperature | -30~80 |
| Touch screen | Support custom capacitive touch and resistive touch |
| Application | Advertising display, medical, automotive, IoT, home application, Gas equipment, Medical, Industrial control, Elevator, Car automation, Surveillance video. |
The 7.0 inch 1024*600 TFT display module can be used for Advertising display, medical, automotive, IoT, home application, Gas equipment, Medical, Industrial control, Elevator, Car automation, Surveillance video.
