Kingtech 8.0'' inch 800*480 TFT module display supply very stable. This 8.0'' inch supports 24-bit Parallel RGB Interfaceinterface. In addition, the 8.0'' inch TFT display module brightness is 450nits, and this 8.0'' inch screen is All viewing type. For the touch part, we can also customize capacitive and resistive touch according to the customer requirements.
Stable supply
WVGA / 800*480 resolution
Can custom resistive touch and capacitive touch
Life-time 50000h
Contrast Ratio 500
Get a Quote
Documentation
| Item | 8.0 inch IPS800*480 TFT isplay |
| Model No. | PV08019Y0150V |
| Resolution | 800*480 |
| Outline Dimension (mm) | 192.8*116.9*6.4 |
| Active Area (mm) | 176.64*99.36 |
| Viewing Angle | All |
| Brightness | 450nits |
| Interface | 24-bit Parallel RGB Interface |
| Backlight | / |
| Driving IC | / |
| PIN No. | 50 |
| Operating Temperature | -20~70C |
| Storage Temperature | -30~80C |
| Touch screen | Can custom resistive and capacitive touch screen |
| Application | E-Bike, Medical, hand-held device, industrial |
The 8.0'' inch 800*480 TFT display module can be used for Medical, hand-held device, industrial, Smart-home, outdoor, Elevator, Access Control device or others
