Kingtech 27'' inch 1920*1080 TFT module display supply very stable. This 27'' inch supports LVDS interface. In addition, the 27'' inch TFT display module brightness is 400nits, and this 27'' inch screen is All viewing type. For the touch part, we can also customize capacitive and resistive touch according to the customer requirements.
Stable supply
Can custom resistive touch and capacitive touch
High Color Saturation: 72% NTSC
High Contrast Ratio: 4000:1
FHD Resolution (1920 x 1080)
| Item | 27'' IPS 1920*1080 TFT display |
| Model No. | PV02701S0730C |
| Resolution | 1920*1080 |
| Outline Dimension (mm) | 630*368.2*13 |
| Active Area (mm) | 597.88*336.312 |
| Viewing Angle | All |
| Brightness | 400nits |
| Interface | LVDS |
| Backlight | 12*8LEDs |
| Driving IC | / |
| PIN No. | 30 |
| Operating Temperature | -20-70C |
| Storage Temperature | -30~80C |
| Touch screen | Can custom resistive and capacitive touch screen |
| Application | E-Bike, Medical, hand-held device, industrial |
The 27'' inch 1920*1080 TFT display module can be used for Medical, hand-held device, industrial, outdoor, Elevator, Access Control device, advertising and others.
