Kingtech 4.3 inch 480x272 IPS LCD display supply is very stable. This 4.3 inch TFT module supports the RGB interface. In addition, the 4.3inch WQVGA screen used ST7283 driver IC. It with IPS/full/ all /wide viewing angle. For the touch part, Kingtech can custom the touch panel according to the customer's requirements.
IPS / Full / All / Wide viewing angle
480x272 / WQVGA resolution
ST7283 IC
Existing capacitive and resistive touch panel
RGB interface
Get a Quote
Documentation
| Item | 4.3-inch 480X272 RGB interface LCD module |
| Model No | PV043014HZ40P-R |
| Resolution | 480x272 / WQVGA |
| Outline Dimension | 105.5*67.2*3.0 |
| Active Area(mm) | 95.04*53.86 |
| Interface | RGB |
| Driver IC | ST7283 |
| Brightness | 400/800nits |
| Viewing Angle | All |
| LED life | 30000h |
| Display Mode | Transmissive / Normally black |
| PIN | 40 |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
| Touchscreen | Can custom capacitive/resistive touchscreen |
The 4.3 inch 480x272 IPS LCD module can be used for agricultural equipment, medical device, game console, and smart home, etc.
