Kingtech2.0 inch 240x320 resolution TFT LCD display. It with stable production. This 2.0 inch TFT LCD display supports MCU, RGB, SPI 3len interface, ST7789V2 driver IC. It with 8:00 viewing angle. The 2.0inch QVGA is transflective LCD module and can be used for outdoor device. For the touch part, we can also customize capacitive and resistive touch according to the customer requirements.
Small LCD display
IPS /Free/All/Wide viewing angle
Can custom resistive touch and capacitive touch
Medical, hand-held device, industrial, smart watch
Transflective /Sunlight readable/140nits/Outdoor
Get a Quote
Documentation
| Item | 2.0 inch 240x320 small size transflective LCD display |
| Model No. | PV02016Y0840U |
| Resolution | 240*320 |
| Outline Dimension (mm) | 38.52*52.74*2.69 |
| Active Area (mm) | 30.60*40.80 |
| Viewing Angle | 8 O'clock |
| Brightness | 140nits |
| Interface | MCU 、RGB、SPI 3len |
| Backlight | 1*4LED |
| Driving IC | ST7789V2 |
| PIN No. | 40 |
| Operating Temperature | -30~70C |
| Storage Temperature | -40~80C |
| Touch screen | Can custom resistive and capacitive touch screen |
| Application | Medical, hand-held device, industrial, smart watch, E-bike, Outdoor |
The 2.0inch transflective QVGA TFT LCD module used for Medical, hand-held device, industrial, outdoor, Elevator, Access Control device, advertising, ATM, E-bike, EV-Chargers, Personal Navigation Device, Multimedia applications and Others AV system, GPS, Personal Navigation Device, meter, vehicle, motorcycle, farm equipment, HMI, Portable DVD, marine, POS terminal, thermostat, access control, elevator, video door, consumer electronics, Gas equipment, charging piles/engineering vehicles/ships, automotive and 3D printer.
