Kingtech 3.2 inch 240*320 TFT display supply very stable. This 3.2 inch supports MCU 8Bit interface. In addition, the 3.2 inch 240*320 TFT display module brightness is 400 nits, and this 3.2 inch display is All viewing type. For the touch part, we can also customize capacitive and resistive touch according to the customer requirements.
3.2 inchTFT display
240*320/QVGA
Stable supply
All/Full/IPS/Wide viewing angle
MCU 8Bit interface
400nits~1000nits brightness/Sunlight readable/High brightness
Can custom resistive touch and capacitive touch
Medical, hand-held device, industrial
Get a Quote
Documentation
| Item | 3.2 inch IPS 240*320 TFT display |
| Model No. | PV032QV-BIA2001 |
| Resolution | 240*320 |
| Outline Dimension (mm) | 55.04*77.70*2.35 |
| Active Area (mm) | 48.60*64.80 |
| Viewing Angle | All |
| Brightness | 400nits |
| Interface | MCU 8Bit |
| Backlight | 1*6LED |
| Driving IC | ST7789Z3 |
| PIN No. | 20 |
| Operating Temperature | -20~70 |
| Storage Temperature | -30~80 |
| Touch screen | Can custom resistive and capacitive touch screen |
| Application | Medical, hand-held device, industrial, smart home |
The 3.2 inch 240*320 TFT display module can be used for E-Bike, Medical, hand-held device, industrial or others.
