Kingtech 5-inch TFT LCD display. It LCD panel has Full viewing angle using IPS technology and resolution 720x1280.LCD driver ic is GC9702C.
Its backlight is 6*2 LED, and brightness is 450nits. It is with capacitive touch screen, tape bonding or OCA bonding can be available. Its LCD FPC is 30pins, MIPI DSI interface.
It is applicable for Handheld device, Medical, Smart Home, IoT, POS, Mobile phone, etc.
The module works within the temperatures -20 to +70, and the storage temperature covers from -30 to +80.
TFT display
PV05028T0225Z-CO
720*1280/HD
Stable supply
All / Wide/Full viewing angle
MIPII interface
500nits brightness
OCA bonding Capacitive touch
Medical, industrial, Smart Home Appliance, Security device
Get a Quote
Documentation
| Item | 5 inch TFT 720x1280 module display |
| Model No. | PV05028T0225Z-CO |
| Resolution | 720*1280/HD |
| Outline Dimension (mm) | 72.10*130.10*3.15 |
| Active Area (mm) | 62.10*111.00 |
| Viewing Angle | IPS |
| Brightness | 450nits |
| Interface | MIPI |
| Backlight | 6*2LED |
| Driving IC | GC9702C+CHSC5448 |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
| Touch screen | OCA capacitive touch screen |
| Application | Phone, Medical, hand-held device, industrial, Smart home Appliance |
The 5 inch HD 720x1280 TFT display module can be used for Handheld device, Medical, Smart Home Appliance, industrial or others.
