Kingtech 10.1 inch 1280*800 IPS LCD display supply is very stable. This 10.1inch supports the LVDS interface. In addition, the 10.1 inch TFT module has an existing HDMI Board. It can connect to the raspberry pi directly. The lifetime is 20000h, brightness is 350nits and can be customized to 1000nits sunlight readable, and this 10.1-inch screen is All/Free/Wide viewing angle/IPS type. For the touch part, Kingtech can custom the touch according to the customer's requirements.
All/Free/All/Wide viewing angle/IPS
1280x800 / WXGA
Stable supply
HDMI board / Convert board
Capacitive touch IIC and USB interfaces
Wide temperature/-20℃~+70℃
Cost effective 350nits brightness can be up to high brightness/Sunlight readable/outdoor/1000nits
Can custom capacitive touch screen
Get a Quote
Documentation
| Item | 10.1inch 1280x800 touch screen module |
| Model No | PV101026LZR40U-CO |
| Resolution | 1280x800 / WXGA |
| Outline Dimension | 229.46(W)×149.10(H)×4.80(T) |
| Active Area(mm) | 216.96(W)×135.60(H) |
| Interface | LVDS |
| Brightness | 350~1000nits |
| Viewing Angle | All |
| LED life | 20000h |
| Display Mode | TN / Transmissive / Normally Black |
| PIN | 30 |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
| Board | Convert Board |
| Touchscreen | Can custom capacitive touchscreen |
The 10.1inch 1280x800 IPS TFT LCD display can be used for agricultural equipment, medical device, game console, outdoor and smart home, etc.
