Kingtech 5.0'' inch 640*480 TFT module display supply very stable. This 5.0'' inch supports RGBinterface. In addition, the 5.0'' inch TFT display module brightness is 800nits, and this 5.0'' inch screen is 12 O'clock viewing type. For the touch part, we can also customize capacitive and resistive touch according to the customer requirements.
Stable supply
800nits brightness/Sunlight readable/High brightness/Outdoor
Can custom resistive touch and capacitive touch
Life-time 50000h
Contrast Ratio 500
Get a Quote
Documentation
| Item | 5.0 inch TN 640*480 TFT display |
| Model No. | PV05039D0150L |
| Resolution | 640*480 |
| Outline Dimension (mm) | 117.65*88.43*5.7 |
| Active Area (mm) | 101.57*76.18 |
| Viewing Angle | 12 O'clock |
| Brightness | 800nits |
| Interface | RGB |
| Backlight | 3*6LEDs |
| Driving IC | / |
| Operating Temperature | -20~70C |
| Storage Temperature | -30~80C |
| Touch screen | Can custom resistive and capacitive touch screen |
| Application | E-Bike, Medical, hand-held device, industrial |
The 5.0'' inch 640*480 TFT display module can be used for Medical, hand-held device, industrial, Smart-home, outdoor, Elevator, Access Control device, advertising, ATM, E-bike, EV-Chargers, Personal Navigation Device, Multimedia applications and Others AV system, GPS, Personal Navigation Device, meter, vehicle, motorcycle, farm equipment, HMI, Portable DVD, marine, POS terminal, thermostat, access control, elevator, video door, consumer electronics, Gas equipment or others.
