Kingtech 2.4 inch 240*320 TFT module display supply is very stable. This 2.4 inch QVGA supports the MCU interface. In addition, the 2.4 inch TFT display module is 840 nits high brightness, and this 2.4-inch screen is TN /6 O'clock viewing angle type. For the touch part, we also can customize capacitive touch according to the customer requirements.
TFT display
240*320 / QVGA
Stable supply
850nits high brightness / Outdoor / Sunlight readable
small display
MCU interface
Medical / Hand-held/ Industrial /POS machine
Can custom resistive and capacitive touch screen
Get a Quote
| Item | 2.4 inch TFT display module |
| Model No | PV024002YP40C |
| Resolution | 240*320 |
| Outline Dimension | 59.91*42.80*2.40 |
| Active Area(mm) | 48.96*36.72 |
| Brightness | 850 nits |
| Viewing Angle | 6 O'clock/ TN |
| Interface | MCU interface |
| Driving IC | ST7789VI |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
| Touch screen | Can custom resistive and capacitive touch screen |
The 2.4 inches 240*320 TFT display module can be used for medical, Hand-held, Industrial and POS machines.
