Kingtech 3.5 inch 320x240 resolution TFT LCD display. It with stable production. This 3.5 inch TFT LCD display supports sunlight readable, RGB interface, ST7272 driver IC. It with all viewing angle. Mainly application for e-Bike, hand-held device, outdoor application. For the touch part, we can also customize capacitive and resistive touch according to the customer requirements.
Sunlight readable - high brightness - 1000nits brightness
IPS/All/Wide/Free viewing angle
Can custom resistive touch and capacitive touch
Medical, hand-held device, industrial, Outdoor
Get a Quote
Documentation
| Item | 3.5 inch 320x240 resolution 1000nits LCD display |
| Model No. | PV03527H0554A |
| Resolution | 320*240 |
| Outline Dimension (mm) | 76.40*63.50*2.92 |
| Active Area (mm) | 70.08*52.56 |
| Viewing Angle | All |
| Brightness | 1000nits |
| Interface | RGB |
| Backlight | 4*2LED |
| Driving IC | ST7272A |
| PIN No. | 54 |
| Operating Temperature | -20~70C |
| Storage Temperature | -30~80C |
| Touch screen | Can custom resistive and capacitive touch screen |
| Application | Medical, hand-held device, industrial, E-bike, EV-charger |
The 3.5inch QVGA TFT LCD display can be Medical, hand-held device, industrial, outdoor, Elevator, Access Control device, advertising, ATM, E-bike, EV-Chargers, Personal Navigation Device, Multimedia applications and Others AV system, GPS, Personal Navigation Device, meter, vehicle, motorcycle, farm equipment, HMI, Portable DVD, marine, POS terminal, thermostat, access control, elevator, video door, consumer electronics, Gas equipment, charging piles/engineering vehicles/ships, automotive and 3D printer.
