Kingtech 5inch 800x480 /WVGA TFT LCD display is one of Kingtech's main products. The 5inch LCD screen can be supplied for a long time.
This display has the existing resistive touch and capacitive touch. Kingtech display can custom LCD module according to customer requirements. This 5inch display can reach 1000nits and can be used for outdoor devices. The 5inch module has HDMI Board.
800x480 / WVGA resolution
Landscape
High brightness/sun readable LCD/1000nits
Support resistive touch and capacitive touch
HDMI Board
Get a Quote
Documentation
| Item | 500nit/1000 nit 5-inch TFT LCD display |
| Model No | PV05009HZ40L |
| Resolution | 800*480 |
| Outline Dimension | 120.7*75.8*2.9 |
| Active Area(mm) | 108*64.80 |
| Interface | 24-bit Parallel RGB |
| Brightness | 500nits / 1000nits |
| Board | HDMI board |
| Viewing Angle | 12 o'clock |
| Driving IC | ILI6122+ILI5960 |
| Display Mode | Transmission / Normally White |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
| Touch screen | Resistive / capacitive touch screen |
The 5inch 800x480 / WVGA TFT LCD display can be used for medical devices, handheld equipment, industrial control, smart home, E-bike, and Navigator device.
The 5inch TN 1000nits also can be used in sunlight-readable such as advertising machines, automotive devices.
