Kingtech PV05036B0140H is 5.0inch Transflecitve TFT LCD module. Transflective LCD is a special glass designed for outdoor application. Its working temperature is wide temperature -30-85. Its viewing angle is TN, IPS panel technology. The resolution is 800x480. It supports RGB interface. Although its brightness is only 200nits, it is sunlight readable. It is designed for outdoor application, such as motorcycle, industrial PLC, car, etc.
Transflective, Sunlight readable, Outdoor device
Wide working temperature, suitable for harsh environments, -30~+85C.
Capacitive Touch or resistive touch optional
Power saving
Designed for outdoor use
Get a Quote
Documentation
| Item | 5inch WVGA Transfletive LCD display for sunlight readable |
| Model No. | PV05036B0140H |
| Resolution | 800*480 |
| Outline Dimension (mm) | 120.70*75.80*5.0 |
| Active Area (mm) | 108*64.8 |
| Viewing Angle | 6 O'clock |
| Brightness | 200nits |
| Interface | RGB |
| Backlight | / |
| Driving IC | / |
| PIN No. | 40 |
| Operating Temperature | -30~85C |
| Storage Temperature | -30~85C |
| Touch screen | Resistive touch and capacitive touch for optional |
| Application | Outdoor application, handheld device, E-bike, Industrial, Medical, Sunlight readable, EV-Chargers. |
It is applicable for Medical, hand-held device, industrial, outdoor, advertising, E-bike, EV-Chargers, meter, vehicle, motorcycle, farm equipment, HMI, Portable DVD, marine, POS terminal, thermostat, access control, elevator, video door, consumer electronics, charging piles/engineering vehicles/ships, automotive and 3D printer.
