Kingtech 3.5 inch 320x480 IPS LCD display supply is very stable. This 3.5inch supports 8-/ 9-/16-/18- 8080-MCU, 4-lines /3-lines SPI+16-/18-bit RGB interface. In addition, the 3.5 inch TFT module has the existing resistive touch and a capacitive touch panel. The lifetime is 30000h, this LCD screen is All/Free/Wide viewing angle/IPS type. For the touch part, Kingtech can custom the touch according to the customer's requirements.
All/Free/Wide viewing angle/IPS
320x480
Vertical / Portrait type
Stable supply
ILI9488 IC
Support resistive touch and capacitive touch panel
Support MCU, SPI, and RGB interfaces
Get a Quote
Documentation
| Item | 3.5 inch IPS 320x480 LCD display |
| Model No | PV035HV-CIA5007-CO |
| Resolution | 320*480 |
| Outline Dimension | 54.66*84.18*3.65 |
| Active Area(mm) | 48.96*73.44 |
| Interface | 8-/ 9-/16-/18- 8080-MCU4-lines / 3-lines SPI + 16-/18-bit RGB |
| Brightness | 350nits |
| Viewing Angle | All |
| LED life | 30000h |
| Display Mode | Transmissive, Normally black |
| PIN | 50 |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
| Touchscreen | Support resistive touch and capacitive touch |
| Touchscreen | Can custom capacitive and resistive touch |
The 3.5 inch IPS 320x480 TFT LCD display can be used for agricultural equipment, medical device, game console, and smart home, etc.
