Kingtech 10.1inch 1280x800 landscape IPS All / free/ wide viewing angle TFT LCD display is one of our main products.
The 10.1inch LVDS TFT LCD module has capacitive touch and support I2C and USB interfaces. The 10.1inch TFT screen has HDMI Board, it can be connected with Raspberry Pi to operate. This 10.1inch IPS display can support -30~+80C for operating temperature.
Kingtech Diaplay will provide the customers with qualified standard dispalys and satisfying one-stop services. Any requests will be welcomed.
1280x800 resolution/High definition resolution
All / Free / Wide viewing angle
IPS type
Wide operating temperature/ -30~+80C
Landscape display
Support capacitive touch 12C and USB interfaces
Support HDMI Board
Get a Quote
Documentation
| Item | kingtech 10.1 inch ips1280x800 display |
| Model No. | PV101011LZR40J-C |
| Resolution | 1280 x 800 |
| Outline Dimension | 229.80(W) x 149.00(H) x 5.95(T) |
| Active Area(mm) | 216.96(W) x 135.60(H) |
| Brightness | 500nits - 1000nits |
| Touch screen | I2C / USB IPS capacitive touchscreen |
| Interface | 8-BIT LVDS Interface |
| Viewing Angle | All |
| LED life | 50000h |
| Display Mode | Transmissive / Normally Black |
| Operating Temperature | -30℃ to +80℃ |
| Storage Temperature | -30℃ to +80℃ |
| Board | HDMI board |
The 10.1inch 1280x800 500nits IPS TFT LCD display can be used for medical devices, handheld equipment, industrial control, smart home, logistics device, and E-Bike.
