Kingtech 8inch 800x1280 IPS All / free/ wide viewing angle TFT LCD display is the most popular size in the market.
The 8inch TFT module has a special resolution of 800x1280, and the interface is MIPI 4 lane. The 8inch IPS LCD screen has a capacitive touch and also can custom TFT display according to customer requirements.
Kingtech Diaplay, as one of LCD display panel manufacturers, has achieved great progresses in the field of LCD production. We promoise that we will provide the customers with qualified standard dispalys and satisfying one-stop services. Any requests will be welcomed.
800x1280 resolution
All / Free / Wide viewing angle
MIPI 4 lane interface
Portrait / vertical display
Support capacitive touch
| Item | 8 inch 800x1280 TFT module display |
| Model No | PV08002TD25E-C |
| Resolution | 800x1280 |
| Outline Dimension | 125.6*231.6*4.86 |
| Active Area(mm) | 107.64*172.22 |
| Interface | MIPI-4 Lanes |
| Viewing Angle | All |
| Display Mode | IPS/Normally Black |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
| Brightness | 380nits |
| Touch panel | Capacitive touch panel |
The 8inch 800x1280 IPS TFT LCD display can be used for medical devices, handheld equipment, industrial control, smart home, logistics device, and E-Bike.
