Kingtech 3.5 inch 320*480 UART Serial HMI Display Module supply very stable. This 3.5 inch HVGA supports MCU interface /RGB interface, ILI9488 or compatible Driver IC. In addition, the 3.5 inch TFT module brightness is 300nits, and this 3.5 inch screen is 12 O' Clock/ TN viewing angle type. For the touch part, can provide capacitive and resistive touch.
Landscape / Horizontal
320*480 / HVGA
Stable supply
TTL UART (TXD/RXD) interface
Provide capacitive touch and resistive touch
Industrial equipment/medical device/smart home
Get a Quote
Documentation
| Item | 3.5 inch 320*480 Resolution UART Serial |
| Model No | PVS035320480M002 |
| Resolution | 320*480 |
| Outline Dimension | 55.50(W)*84.96(H)*2.45(T) |
| Active Area(mm) | 48.96(W)*73.44(H) |
| Viewing Angle | 12 O' Clock |
| Driver IC | ILI9488, NT35310 or compatible |
| Interface | MCU interface /RGB interface |
| Pixel pitch (L*W) | 0.153*0.153 |
| Backlight Luminance | 300nits |
| Operating Temperature | -20 to +70℃ |
| Storage Temperature | -30 to +80℃ |
| Touch screen | Resistive touch |
The 3.5 inch 320*480 UART Serial Display Module can be used for agricultural equipment, medical device, and smart home etc.
